Electrical Specifications @ 25℃

Part

Number

Turn

Ratio

Insertion

Loss

0.5~100MHz

(dB Max)

Return Loss

(dB Min)

Cross Talk

(dB Min)

CMRR

(dB Min)

CWW

(pF Max)

LK

(uH Max)

DCR

(Ω Max)

Hi-Pot

(Vrms

MIN)

Tx

Rx

0.5-30

MHz

30.1-60

MHz

60.1-80

MHz

0.5-40

MHz

40.1-100

MHz

0.50-100

MHz

QT40A01

1:1

1:1

-1.0

-16

-14

-12

-35

-30

-30

56

0.5

1.2

1500
