Electrical Specifications @ 25℃

Part Number

Turn Ratio

Insertion Loss 0.5~100MHz (dB Max)

Return Loss (dB Min)

Cross Talk (dB Min)

CMRR (dB Min)

CWW (pF Max)

LK (uH Max)

DCR (Ω Max)

Hi-Pot (Vrms MIN)

Tx

Rx

0.5-30  MHz

30.1-60 MHz

60.1-80 MHz

0.5-40 MHz

40.1-100 MHz

0.50-100  MHz

QT50A03

1:1

1:1

-1.0

-16

-14

-12

-35

-30

-30

28

0.5

1.2

1500
